An organization uses one specific CloudHub (AWS) region for all CloudHub deployments. How are CloudHub workers assigned to availability zones (AZs) when the organization's Mule applications are deployed to CloudHub in that region?

1. A. Workers belonging to a given environment are assigned to the same AZ within that region.
2. B. AZs are selected as part of the Mule application's deployment configuration.
3. C. Workers are randomly distributed across available AZs within that region.
4. D. An AZ is randomly selected for a Mule application, and all the Mule application's CloudHub workers are assigned to that one AZ

Correct Answer: C
Correct answer is Workers are randomly distributed across available AZs within that region. This ensure high availability for deployed mule applications Mulesoft documentation reference :
https://docs.mulesoft.com/runtime-manager/cloudhub-hadr

A customer wants to use the mapped diagnostic context (MDC) and logging variables to enrich its logging and improve tracking by providing more context in the logs.
The customer also wants to improve the throughput and lower the latency of message processing.
As an Mulesoft integration architect can you advise, what should the customer implement to meet these requirements?

1. A. Use synchronous logging and use pattern layout with [%MDC] in the log4j2.xml configuration file and then configure the logging variables
2. B. Useasync logger at the level greater than INFO and use pattern layout with [%MDC] in the log4j2,xml configuration file and then configure the logging variables
3. C. Useasync logger at the level equal to DEBUG orTRACEand use patternlayout with [%MDC] in the log4j2.xml configuration file and then configure the logging variables
4. D. Use synchronous logging at the INFO DEBUG or Trace level and use pattern layout with [%MDC] in the log4j2.xml configuration file and then configure the logging variables

Correct Answer: B

An organization has chosen Mulesoft for their integration and API platform.
According to the Mulesoft catalyst framework, what would an integration architect do to create achievement goals as part of their business outcomes?

1. A. Measure the impact of the centre for enablement
2. B. build and publish foundational assets
3. C. agree upon KPI's and help develop and overall success plan
4. D. evangelize API's

Correct Answer: C

Refer to the exhibit.
An organization is designing a Mule application to receive data from one external business partner. The two companies currently have no shared IT infrastructure and do not want to establish one. Instead, all communication should be over the public internet (with no VPN).
What Anypoint Connector can be used in the organization's Mule application to securely receive data from this external business partner?

1. A. File connector
2. B. VM connector
3. C. SFTP connector
4. D. Object Store connector

Correct Answer: C
* Object Store and VM Store is used for sharing data inter or intra mule applications in same setup. Can't be used with external Business Partner
* Also File connector will not be useful as the two companies currently have no shared IT infrastructure. It's specific for local use.
* Correct answer is SFTP connector. The SFTP Connector implements a secure file transport channel so that your Mule application can exchange files with external resources. SFTP uses the SSH security protocol to transfer messages. You can implement the SFTP endpoint as an inbound endpoint with a one-way exchange pattern, or as an outbound endpoint configured for either a one-way or request-response exchange pattern.

An organization uses a set of customer-hosted Mule runtimes that are managed using the Mulesoft-hosted control plane. What is a condition that can be alerted on from Anypoint Runtime Manager without any custom components or custom coding?

1. A. When a Mule runtime on a given customer-hosted server is experiencing high memory consumption during certain periods
2. B. When an SSL certificate used by one of the deployed Mule applications is about to expire
3. C. When the Mute runtime license installed on a Mule runtime is about to expire
4. D. When a Mule runtime's customer-hosted server is about to run out of disk space

Correct Answer: A
Correct answer is When a Mule runtime on a given customer-hosted server is experiencing high memory consumption during certain periods Using Anypoint Monitoring, you can configure two different types of alerts: Basic alerts for servers and Mule apps Limit per organization: Up to 50 basic alerts for users who do not have a Titanium subscription to Anypoint Platform You can set up basic alerts to trigger email notifications when a metric you are measuring passes a specified threshold. You can create basic alerts for the following metrics for servers or Mule apps: For on-premises servers and CloudHub apps: * CPU utilization * Memory utilization * Thread count Advanced alerts for graphs in custom dashboards in Anypoint Monitoring. You must have a Titanium subscription to use this feature. Limit per organization: Up to 20 advanced alerts
