- (Exam Topic 3)
Your company has offices in Montreal. Seattle, and Paris. The outbound traffic from each office originates from a specific public IP address.
You create an Azure Front Door instance named FD1 that has Azure Web Application Firewall (WAF) enabled. You configure a WAF policy named Policy! that has a rule named Rule1. Rule1 applies a rate limit of 100 requests for traffic that originates from the office in Montreal.
You need to apply a rate limit of 100 requests for traffic that originates from each office. What should you do?

1. A. Modify the conditions of Rule1.
2. B. Create two additional associations.
3. C. Modify the rule type of Rule1.
4. D. Modify the rate limit threshold of Rule1.

Correct Answer: A

- (Exam Topic 3)
FirewallPolicy1 contains the following rules:
• Allow outbound traffic from Vnet1 and Vnet2 to the internet.
• Allow any traffic between Vnet1 and Vnet2.
No custom private endpoints, service endpoints, routing tables, or network security groups (NSGs) were created. For each of the following statements, select Yes if the statement is true. Otherwise, select No. NOTE: Each correct selection is worth one point.

Solution:


Does this meet the goal?

1. A. Yes
2. B. No

Correct Answer: A

- (Exam Topic 3)
You have an Azure Front Door instance that has a single frontend named Frontend1 and an Azure Web Application Firewall (WAF) policy named Policy1. Policy1 redirects requests that have a header containing "string1" to https://www.contoso.com/redirect1. Policy1 is associated to Frontend1.
You need to configure additional redirection settings. Requests to Frontend1 that have a header containing "string2" must be redirected to https://www.contoso.com/redirect2.
Which three actions should you perform? Each correct answer presents part of the solution. NOTE: Each correct selection is worth one point.

1. A. Create a custom rule.
2. B. Configure a managed rule.
3. C. Create a frontend host.
4. D. Create a policy.
5. E. Create an association.
6. F. Add a custom rule to Policy1.

Correct Answer: ABE

- (Exam Topic 3)
You are configuring two network virtual appliances (NVAs) in an Azure virtual network. The NVAs will be used to inspect all the traffic within the virtual network.
You need to provide high availability for the NVAs. The solution must minimize administrative effort. What should you include in the solution?

1. A. Azure Standard Load Balancer
2. B. Azure Traffic Manager
3. C. Azure Application Gateway
4. D. Azure Front Door

Correct Answer: A
Reference:
https://docs.microsoft.com/en-us/azure/architecture/reference-architectures/dmz/nva-ha?tabs=cli

- (Exam Topic 3)
You have an Azure application gateway named AGW1 that has a routing rule named Rule1. Rule 1 directs traffic for http://www.contoso.com to a backend pool named Pool1. Pool1 targets an Azure virtual machine scale set named VMSS1.
You deploy another virtual machine scale set named VMSS2.
You need to configure AGW1 to direct all traffic for http://www.adatum.com to VMSS2.
The solution must ensure that requests to http://www.contoso.com continue to be directed to Pool1. Which three actions should you perform? Each correct answer presents part of the solution.
NOTE: Each correct selection is worth one point.

1. A. Add a backend pool.
2. B. Modify an HTTP setting.
3. C. Add an HTTP setting.
4. D. Add a listener.
5. E. Add a rule.

Correct Answer: ADE
Reference:
https://docs.microsoft.com/en-us/azure/application-gateway/configuration-overview
