- (Exam Topic 4)
Note: This question is part of a series of questions that present the same scenario. Each question in the series contains a unique solution that m.ght meet the stated goals. Some question sets might have more than one correct solution, while others might not have a correct solution.
After you answer a question in this section, you win NOT be able to return to it. As a result, these questions win not appear in the review screen.
You integrate a cloud- hosted Jenkins server and a new Azure DevOps deployment
You need Azure DevOps to send a notification to Jenkins when a developer commits changes to a branch in Azure Repos.
Solution: You create a service hook subscription that uses the code pushed event. Does this meet the goal?
Correct Answer:
A
You can create a service hook for Azure DevOps Services and TFS with Jenkins. References:
https://docs.microsoft.com/en-us/azure/devops/service-hooks/services/jenkins
- (Exam Topic 4)
You use Azure Pipelines to automate Continuous Integration/Continuous Deployment (CI/CD) for an Azure web app named WebApp1.
You configure an Azure Monitor alert that is triggered when WebApp1 generates an error.
You need to configure the alert to forward details of the error to a third-party system. The solution must minimize administrative effort.
Which three actions should you perform in sequence? To answer, move the appropriate actions from the list of actions to the answer area and arrange them in the correct order.
Solution:
Graphical user interface, text, application Description automatically generated
Box 1: Create an Azure logic app.
Box 2: Select the HTTP request trigger.
Box 3: Updated the action group in Azure Monitor. Reference:
https://docs.microsoft.com/en-us/azure/azure-monitor/alerts/action-groups-logic-app
Does this meet the goal?
Correct Answer:
A
- (Exam Topic 4)
You have an Azure function hosted in an App Service plan named az400-9940427-func1.
You need to configure az400-9940427-func1 to upgrade the functions automatically whenever new code is committed to the master branch of https://github.com/Azure-Samples/functions-quickstart.
To complete this task, sign in to the Microsoft Azure portal.
Solution:
* 1. Open Microsoft Azure Portal
* 2. Log into your Azure account, select App Services in the Azure portal left navigation, and then select configure az400-9940427-func1.
* 3. On the app page, select Deployment Center in the left menu.
* 4. On the Build provider page, select Azure Pipelines (Preview), and then select Continue.
* 5. On the Configure page, in the Code section:
For GitHub, drop down and select the Organization, Repository, and Branch you want to deploy continuously.
* 6. Select Continue.
* 7. On the Test page, choose whether to enable load tests, and then select Continue.
* 8. Depending on your App Service plan pricing tier, you may see a Deploy to staging page. Choose whether to enable deployment slots, and then select Continue.
* 9. After you configure the build provider, review the settings on the Summary page, and then select Finish. References:
https://docs.microsoft.com/en-us/azure/app-service/deploy-continuous-deployment
Does this meet the goal?
Correct Answer:
A
- (Exam Topic 4)
You have an application named App1 that has a custom domain of app.contoso.com. You create a test in Azure Application Insights as shown in the following exhibit.
Use the drop-down menus to select the answer choice that completes each statement based on the information presented in the graphic.
NOTE: Each correct selection is worth one point.
Solution:
Box 1: every five minutes at a random location
Test frequency: Sets how often the test is run from each test location. With a default frequency of five minutes and five test locations, your site is tested on average every minute.
Box 2:
Parse dependent requests: Test requests images, scripts, style files, and other files that are part of the web page under test. The recorded response time includes the time taken to get these files. The test fails if any of these resources cannot be successfully downloaded within the timeout for the whole test.
Reference:
https://docs.microsoft.com/en-us/azure/azure-monitor/app/monitor-web-app-availability
Does this meet the goal?
Correct Answer:
A
- (Exam Topic 4)
You need to recommend project metrics for dashboards in Azure DevOps.
Which chart widgets should you recommend for each metric? To answer, drag the appropriate chart widgets to the correct metrics. Each chart widget may be used once, more than once, or not at all. You may need to drag the split bar between panes or scroll to view content.
NOTE: Each correct selection is worth one point.
Solution:
Graphical user interface, text, application, chat or text message Description automatically generated
Box 1: Lead time
Lead time measures the total time elapsed from the creation of work items to their completion. Box 2: Cycle time
Cycle time measures the time it takes for your team to complete work items once they begin actively working on them.
Box 3: Burndown
Burndown charts focus on remaining work within a specific time period. Reference:
https://docs.microsoft.com/en-us/azure/devops/report/dashboards/velocity-guidance?view=vsts https://docs.microsoft.com/en-us/azure/devops/report/dashboards/cycle-time-and-lead-time?view=vsts https://docs.microsoft.com/en-us/azure/devops/report/dashboards/configure-burndown-burnup-widgets?view=vs
Does this meet the goal?
Correct Answer:
A
