- (Exam Topic 3)
You have an on-premises network and an Azure subscription. The subscription contains the following virtual network:
* Name:VNet1
* Address space: 10.10.0.0/16
* Subnet name: Subnet1
* Subnet1 address range: 10.10.0.0/16
You deploy an Azure Virtual Desktop host pool that contains 10 session hosts to Subnets.
You plan to deploy a VPN gateway to VNet1 and provide the session hosts with access to the on-premises network.
You need to ensure that you can deploy the VPN gateway.
What should you do first?

1. A. Modify the address range of Subnet1. Most Voted
2. B. Add a subnet named GatewaySubnet to VNet1.
3. C. Modify the address space of VNet1. Most Voted
4. D. Associate a network security group (NSG) to Subnet1.

Correct Answer: B
In order to deploy a VPN gateway to VNet1, you should first add a subnet named GatewaySubnet to VNet1. According to the Microsoft Official Guide AZ-140, "You must create a gateway subnet for the virtual network that you plan to use for the gateway. The subnet must be named GatewaySubnet and it must use an address range that is large enough to accommodate the number of IP addresses that you plan to use for the gateway and its supporting resources." Therefore, the first step to ensure that you can deploy the VPN gateway is to add a subnet named GatewaySubnet to VNet1.

- (Exam Topic 2)
You need to deploy the session hosts to meet the deployment requirements Which PowerShell cmdlel should you run first?

1. A. New-AzwvdRegistratrationinfo
2. B. Get-AzApiManagementSsoToken
3. C. Set-AzWMADDomainExtension
4. D. Update-AZwvdSessionHost

Correct Answer: C
Reference:
https://rozemuller.com/avd-automation-cocktail-avd-automated-with-powershell/

- (Exam Topic 3)
You have a Azure Virtual Desktop host pool named Pool1 that contains three session hosts. The session hosts are configured to use FSLogtx profile containers. You need to configure Cloud Cache on the session hosts. What should you do?

1. A. Remove VHDlocations entries from the Windows registry.
2. B. Configure FSLogtx Office Container.
3. C. Add VHDlocations entries to the Windows registry.
4. D. Uninstall the FSLogix agent

Correct Answer: A
Reference:
https://docs.microsoft.com/en-us/fslogix/configure-cloud-cache-tutorial

- (Exam Topic 3)
You have an Azure Virtual Desktop host pool. The pool contains session hosts that run Windows 10 Enterprise multi-session.
You connect to a Remote Desktop session on Pool1 and discover an issue with the frequency of screen updates.
You need to identify whether the issue relates to insufficient server, network, or client resources. The solution must minimize how long it takes to identify the resource type.
What should you do?

1. A. From within the current session, use the Azure Virtual Desktop Experience Estimator.
2. B. From Azure Cloud Shell, run theGet-AzOperationalInsightsWorkspaceUsage cmdlet and specify the DefaultProfile parameter.
3. C. From Azure Cloud Shell, run the Get-AzWvdUserSession cmdlet and specify the UserSessionId parameter.
4. D. From within the current session, use Performance Monitor to display the values of all the RemoteFX Graphics(*)\Frames Skipped/Second counters.

Correct Answer: D
Reference:
https://docs.microsoft.com/en-us/azure/virtual-desktop/remotefx-graphics-performance-counters

- (Exam Topic 3)
You have a shared image gallery that contains the Windows 10 images shown in the following table.

You create a Windows Virtual Desktop deployment that has the following settings:
Host pool name: Pool1
Location: West US
Host pool type: Personal
Which images can you use for the session hosts?

1. A. Image1 only
2. B. Image1, Image2, Image3, and Image4
3. C. Image2 only
4. D. Image1 and Image2 only
5. E. Image1 and Image3 only

Correct Answer: E
Reference:
https://azure.microsoft.com/en-in/blog/vm-image-blog-post/
