Refer to the exhibit

There is a call flow between Phone A and Phone B Phone B (holder) places Phone A (holder) on hold Which MRGL and Audio Source are played to Phone A?

1. A. MRGL A and Audio Source 4
2. B. MRGL B and Audio Source 4
3. C. MRGL A and Audio Source 2
4. D. MRGL B and Audio Source 2

Correct Answer: C

An administrator is configuring LDAP tor Cisco UCM with Active Directory integration. A customer has requested to use “ipphone” instead of “telephoneNumber” as the phone number attribute. Where does the administrator specify this attribute mapping in Cisco UCM?

1. A. LDAP Custom Filter
2. B. LDAP Directory user fields
3. C. LDAP Directory custom user fields
4. D. LDAP Authentication

Correct Answer: B

Refer to the exhibit.

The SDP offer/answer has been completed successfully but there is no DTMF when users press keys. What is the cause of the issue?

1. A. Payload type 110 was negotiated rather than type 101.
2. B. DTMF was negotiated property in these messages.
3. C. DTMF was not negotiated on the call.
4. D. G.729 rather than G.711ulaw was negotiated.

Correct Answer: C

A Company s employees have been complaining that they have been unable to select options on the internal IVR of the help desk. IT support has been given Cisco UCM traces and below is the snippet of the SDP of the INVITE packet.

How is this issue resolved?

1. A. Configure CODEC for G.729.
2. B. Configure DTMF for KPML.
3. C. Configure CODEC for G.722.
4. D. Configure DTMF for RFC 2833.

Correct Answer: B

A customer reports that the Cisco UCM toll-fraud prevention does not work correctly, and the customer is receiving charges for unapproved international calls as a result. Which two configuration changes resolve the issues? (Choose two.)

1. A. Mark patterns as off-net or on-net.
2. B. Modify the Block OffNet to OffNet Transfer service parameter.
3. C. Disable call forwarding on the phone.
4. D. Use Cisco Unified Border Element to debug the calls.
5. E. Make the calls route through a firewall.

Correct Answer: AB
