A network engineer needs to upgrade the EPLDs of the fabric modules for a Cisco MDS director-class switch. In which order are components reloaded during the process?

1. A. one fabric module at the time
2. B. all fabric modules followed by the entire switching platform
3. C. all fabric modules in parallel
4. D. one module and one supervisor at the time

Correct Answer: C
https://www.cisco.com/c/en/us/td/docs/switches/datacenter/mds9000/sw/7_3/release
_notes/epld/epld_rn_7x.html
Graphical user interface, text, application Description automatically generated

A POAP-enabled Cisco Nexus switch will not enter POAP mode. Which two conditions should be verified? (Choose two.)

1. A. Bootflash must contain a special directory named POAP with poap.py file.
2. B. The switch is in bootup process.
3. C. No startup configuration is available.
4. D. The license file is missing on the switch.
5. E. No Cisco NX-OS image is present on the bootflash.

Correct Answer: BC
POAP is an automatic provisioning and zero-touch deployment feature that assists device owners in the initial deployment and configuration of Nexus switches.
The feature works by checking for a local configuration script. If the script has been deleted, the switch has been reset to factory settings, or this is the first boot-up, the POAP daemon will connect to a preset list of servers to download an initial configuration file.
To perform this operation, the switch must first obtain an IP address from a local DHCP server. POAP configuration settings can also be passed through the DHCP response.
Which conditions should be verified, so they need to be TRUE. Like no startup (A) and bootup (B). C means that it needs to miss a license file and E means it needs to miss an NX-OS image.

Refer to the exhibit.

An engineer is connecting a Cisco MDS 9700 Series Multilayer Director to a downstream Cisco Nexus 5672UP switch. Which command set must be used to complete the configuration?
A)

B)

C)

D)

1. A. Option A
2. B. Option B
3. C. Option C
4. D. Option D

Correct Answer: A

An engineer needs a utility to translate traditional Nexus CLI inputs and generate Python code using XML and JSON message formats. The solution needs to be available on a Nexus 7700 series switch. Which utility should be used?

1. A. NX-OS JSON-RPC
2. B. NX-API Sandbox
3. C. Guest Shell for NX-OS
4. D. Open NX-OS

Correct Answer: B
https://developer.cisco.com/docs/nx-os/#!nx-api-cli-developer-sandbox

Which configuration generates a syslog message when CPU utilization is higher than 60%?

1. A. event manager applet HIGH-CPUevent snmp oid 1.3.6.1.4.1.9.9.109.1.1.1.1.6.1 get-type exact entry-op gt 60 poll-interval 5 action 1.0 syslog priority notifications msg "cpu high"
2. B. event manager applet HIGH-CPUevent snmp oid 1.3.6.1.4.1.9.9.109.1.1.1.1.6.1 get-type exact entry-op lt 60 poll-interval 5 action 1.0 syslog priority notifications msg "cpu high"
3. C. event manager applet HIGH-CPUevent snmp oid 1.3.6.1.4.1.9.9.109.1.1.1.1.6.1 get-type next entry-op gt 60 poll-interval 5 action 1.0 syslog priority notifications msg "cpu high"
4. D. event manager applet HIGH-CPUevent snmp oid 1.3.6.1.4.1.9.9.109.1.1.1.1.6.1 get-type next entry-op lt 60 poll-interval 5 action 1.0 syslog priority notifications msg "cpu high"

Correct Answer: A
https://www.cisco.com/c/en/us/support/docs/ip/internet-protocol-ip/200931-EEM-Subsystem-in-Order-to
Monitor-CPU-Tr.pdf
https://blog.ipspace.net/2008/06/generate-snmp-trap-on-high-cpu-load.html
