Refer to the exhibit.

A host with source address 10.10.10.10. sends traffic to multicast group 239.1.1.1. how do the vPC switches forward the multicast traffic?

1. A. If multicast traffic is received on Po11 Switch2, the traffic is forwarded out only one Po20.
2. B. If multicast traffic is received on Po10 Switch1, the traffic is forwarded out on Po1 and Po20.
3. C. If multicast traffic is received on Po11 and Switch2, the traffic is dropped.
4. D. If multicast traffic is received on Switch over the vPC peer-link, the traffic is dropped.

Correct Answer: C
https://www.cisco.com/c/en/us/support/docs/ip/multicast/214140-multicast-forwarding-in-vpc-based-on-loc.htm

Refer to the exhibit.


An engineer is troubleshooting intermittent connectivity issues between the client PC and the DHCP server. What does the last package captured from the Cisco Nexus 2000 Series Switch indicate?

1. A. The DCHP server releases the IP address from the client.
2. B. The client receives an IP address from the DHCP server.
3. C. The DHCP server sends an IP address via a broadcast message.
4. D. The client sends a unicast message to receive an IP address from the DCHP server.

Correct Answer: A

An engineer must configure SAN connectivity in Cisco UCS manager. The requirement is to specify the WWPN of the storage array and set the zoning type to single initiator multiple targets. The engineer must also configure interrupt handling and queues of the vHBA interface. Which two Cisco UCS policies should be used to configure the settings? (Choose two.)

1. A. storage connection policy
2. B. SAN connectivity policy
3. C. vHBA policy
4. D. Fibre Channel adaptor policy
5. E. boot policy

Correct Answer: AD

AN engineer is asked to modify an overridden policy by changing the number of FCNS database entries to 1500 and then generable a massage. What configuration will accomplish this task?

1. A. Option A
2. B. Option B
3. C. Option C
4. D. Option D

Correct Answer: C
The following example modifies an overridden policy by changing the number of FCNS database entries to 1500. It also generates both the configured and the default syslog messages of the default system policy event manager applet fcns_policy override fcns_entries_max_per_switch
event fcns entries max-per-switch 1500 action 1.0 syslog priority warnings msg FCNS DB entries have reached the EEM limit.

Refer to the exhibit.

Which setting must be configured to prevent reuse of passwords?

1. A. No Change Interval
2. B. Change Interval
3. C. History Count
4. D. Change Count

Correct Answer: C
https://www.cisco.com/c/en/us/td/docs/unified_computing/ucs/ucs-manager/GUI-User-Guides/Admin- Management/3-1/b_Cisco_UCS_Admin_Mgmt_Guide_3_1/ b_Cisco_UCS_Admin_Mgmt_Guide_3_1_chapter_011.html
