- (Exam Topic 2)
Refer to the exhibit.

What step resolves the authentication issue?

1. A. use basic authentication
2. B. change the port to 12446
3. C. target 192 168 100 82 in the URI
4. D. restart the vsmart host

Correct Answer: C
he first figure is the output of the “show control connections” command. From this figure we learned that the 192.168.100.82 so we need to connect to this IP address (not 192.168.100.80).

- (Exam Topic 2)
Which network devices secure API platform?

1. A. next-generation intrusion detection systems
2. B. Layer 3 transit network devices
3. C. content switches
4. D. web application firewalls

Correct Answer: D
Reference: https://www.cisco.com/c/en/us/products/collateral/security/advanced-waf-bot-aag.pdf> Cisco® Secure Web Application Firewall (WAF) and bot protection defends your> online presence and ensures that website, mobile applications, and APIs> are secure, protected, and “always on.”

- (Exam Topic 4)
the following system log message is presented after a network administrator configures a GRE tunnel:
%TUN-5-RECURDOWN Interface Tunnel 0 temporarily disabled due to recursive routing Why is tunnel 0 disabled?

1. A. Because dynamic routing is not enabled
2. B. Because the tunnel cannot reach its tunnel destination
3. C. Because the best path to the tunnel destination is through the tunnel itself
4. D. Because the router cannot recursively identify its egress forwarding interface

Correct Answer: C

- (Exam Topic 1)

Refer to the exhibit. An engineer attempts to create a configuration to allow the Blue VRF to leak into the global routing table, but the configuration does not function as expected. Which action resolves this issue?

1. A. Change the access-list destination mask to a wildcard.
2. B. Change the source network that Is specified in access-list 101.
3. C. Change the route-map configuration to VRF_BLUE.
4. D. Change the access-list number in the route map

Correct Answer: A

- (Exam Topic 4)
Which Python code snippet must be added to the script to store the changed interface configuration to a local JSON-formatted file?

1. A. Option A
2. B. Option B
3. C. Option C
4. D. Option D

Correct Answer: B
