- (Exam Topic 2)
How cloud deployments differ from on-prem deployments?

1. A. Cloud deployments require longer implementation times than on-premises deployments
2. B. Cloud deployments are more customizable than on-premises deployments.
3. C. Cloud deployments require less frequent upgrades than on-premises deployments.
4. D. Cloud deployments have lower upfront costs than on-premises deployments.

Correct Answer: C

- (Exam Topic 1)
Refer to the exhibit.

Which HTTP JSON response does the python code output give?

1. A. NameError: name 'json' is not defined
2. B. KeyError 'kickstart_ver_str'
3. C. 7.61
4. D. 7.0(3)I7(4)

Correct Answer: D

- (Exam Topic 1)
A company has an existing Cisco 5520 HA cluster using SSO. An engineer deploys a new single Cisco Catalyst 9800 WLC to test new features. The engineer successfully configures a mobility tunnel between the 5520 cluster and 9800 WLC. Client connected to the corporate WLAN roam seamlessly between access points on the 5520 and 9800 WLC. After a failure on the primary 5520 WLC, all WLAN services remain functional; however, Client roam between the 5520 and 9800 controllers without dropping their connection. Which feature must be configured to remedy the issue?

1. A. mobility MAC on the 5520 cluster
2. B. mobility MAC on the 9800 WLC
3. C. new mobility on the 5520 cluster
4. D. new mobility on the 9800 WLC

Correct Answer: B

- (Exam Topic 1)
Which function in handled by vManage in the cisco SD-WAN fabric?

1. A. Establishes BFD sessions to test liveliness of links and nodes.
2. B. Distributes polices that govern data forwarding.
3. C. Performs remote software upgrades for WAN Edge vSmart and vBond.
4. D. Establishes iPsec tunnels with nodes

Correct Answer: C

- (Exam Topic 1)
Refer to exhibit.

VLANs 50 and 60 exist on the trunk links between all switches All access ports on SW3 are configured for VLAN 50 and SW1 is the VTP server Which command ensures that SW3 receives frames only from VLAN 50?

1. A. SW1 (config)#vtp pruning
2. B. SW3(config)#vtp mode transparent
3. C. SW2(config)=vtp pruning
4. D. SW1 (config >»vtp mode transparent

Correct Answer: A
SW3 does not have VLAN 60 so it should not receive traffic for this VLAN (sent from SW2). Therefore we should configure VTP Pruning on SW3 so that SW2 does not forward VLAN 60 traffic to SW3. Also notice that we need to configure pruning on SW1 (the VTP Server), not SW2.
