- (Exam Topic 3)
Refer to the exhibit.

The forwarding entries how that the next hop for prefixes from the 172.16.0.0/16 network is set to 10.2.2.2 instead of 10.1.1.1. Which action resolves the issue?

1. A. Add set ip next hop 10.1.1.1 in route-map RED permit 20.
2. B. Add the continue statement in route-map RED permit 10 instead of continue 20.
3. C. Remove match ip address prefix-list 1 from route-map RED permit 10.
4. D. Remove the continue 20 statement from route-map RED permit 10

Correct Answer: D

- (Exam Topic 2)
Refer to the exhibit.

AS65510 iBGP is configured for directly connected neighbors. R4 cannot ping or traceroute network 192.168.100.0/24 Which action resolves this issue?

1. A. Configure R4 as a route reflector server and configure R1 as a route reflector client
2. B. Configure R1 as a route reflector server and configure R2 and R3 as route reflector clients
3. C. Configure R4 as a route reflector server and configure R2 and R3 as route reflector clients.
4. D. Configure R1 as a route reflector server and configure R4 as a route reflector client

Correct Answer: D
A route received from one iBGP peer will NOT be advertised to another iBGP peer. Therefore R4 could not receive advertisement for network 192.168.100.0/24. We can overcome this BGP limitation by configuring R1 as a route reflector server and R4 as a route reflector client so that R1 sends advertisements for R4.

- (Exam Topic 1)
An engineer configured the wrong default gateway for the Cisco DNA Center enterprise interface during the install. Which command must the engineer run to correct the configuration?

1. A. sudo maglev-config update
2. B. sudo maglev install config update
3. C. sudo maglev reinstall
4. D. sudo update config install

Correct Answer: A

- (Exam Topic 1)
Refer to the exhibit.

What is the result of applying this configuration?

1. A. The router can form BGP neighborships with any other device.
2. B. The router cannot form BGP neighborships with any other device.
3. C. The router cannot form BGP neighborships with any device that is matched by the access list named “BGP”.
4. D. The router can form BGP neighborships with any device that is matched by the access list named “BGP”.

Correct Answer: C
after bgp session are UP.I configured the CoPP to drop 10.3.3.3 bgp traffic (R3). R3 bgp traffic that matched the ACL 100 is dropped and the state is in IDLE
-------------------------------------------
access-list 100 permit tcp host 10.3.3.3 any eq bgp access-list 100 permit tcp host 10.3.3.3 eq bgp any
!
class-map match-all class-bgp match access-group 100
!
policy-map policy-bgp class class-bgp
drop
!
control-plane
service-policy input policy-bgp
!
The 10.3.3.3 neighbor goes to IDLE

- (Exam Topic 1)

Refer to the exhibit. an engineer is trying to get 192.168.32.100 forwarded through 10.1.1.1, but it was forwarded through 10.1.1.2. What action forwards the packets through 10.1.1.1?

1. A. Configure EIGRP to receive 192.168.32.0 route with lower admin distance.
2. B. Configure EIGRP to receive 192.168.32.0 route with longer prefix than /19.
3. C. Configure EIGRP to receive 192.168.32.0 route with lower metric.
4. D. Configure EIGRP to receive 192.168.32.0 route with equal or longer prefix than /24.

Correct Answer: D
