A virtual server is listening at 10.10.1.100:any and has the following iRule associated with it:
when CLIENT_ACCEPTED { if {[TCP::local_port] equals 80 } { pool pool1 } elseif {[TCP::local_port] equals 443} { pool pool2 }
If a user connects to 10.10.1.100 and port 22, which pool will receive the request?

1. A. pool1
2. B. pool2
3. C. Non
4. D. The request will be dropped.
5. E. Unknow
6. F. The pool cannot be determined from the information provided.

Correct Answer: D

The BIG-IP appliance fails to boot. The BIG-IP Administrator needs to run the End User Diagnostics (EUD) utility to collect data to send to F5 Support.
Where can the BIG-IP Administrator access this utility?

1. A. Console Port
2. B. Internal VLAN interface
3. C. External VLAN interface
4. D. Management Port

Correct Answer: A

Refer to the exhibit.
Which TMSH command generated this output?

1. A. tmsh list /cm sync-status
2. B. tmsh show /sys sync-status
3. C. tmsh list /sys sync-status
4. D. tmsh show /cm sync status

Correct Answer: D

Refer to the exhibit.

A BIG-IP Administrator needs to deploy an application on the BIG-IP system to perform SSL offload and re-encrypt the traffic to pool members.
During testing, users are unable to connect to the application. What must the BIG-IP Administrator do to resolve the issue?

1. A. Remove the configured SSL Profile (Client)
2. B. Configure Protocol Profile (Server) as splitsession-default-tcp
3. C. Enable Forward Proxy in the SSL Profile (Client)
4. D. Configure an SSL Profile (Server)

Correct Answer: D
According to the requirements of the subject, the client and server must be configured with ssl profile.

Which Virtual Server type should be used to load balance HTTP traffic to a pool of servers?

1. A. Standard
2. B. Stateless
3. C. Forwarding (IP)
4. D. Forwarding (Layer 2)

Correct Answer: A
