- (Exam Topic 4)
Refer to the exhibit.

How many objects, Keys and JSON list values are present?

1. A. three objects, two Keys, and three JSON list values
2. B. three objects, three keys and two JSON Ml values
3. C. one object, three keys, and three JSON list values
4. D. one object, three keys and two JSON list values

Correct Answer: C

- (Exam Topic 1)
What is the benefit of using FHRP?

1. A. reduced management overhead on network routers
2. B. balancing traffic across multiple gateways in proportion to their loads
3. C. higher degree of availability
4. D. reduced ARP traffic on the network

Correct Answer: C

- (Exam Topic 2)
Refer to the exhibit.

Router R1 Fa0/0 is unable ping router R3 Fa0/1.
Which action must be taken in router R1 to help resolve the configuration issue?

1. A. set the default network as 20.20.20.0/24
2. B. set the default gateway as 20.20.20.2
3. C. configure a static route with Fa0/1 as the egress interface to reach the 20.20.20.0/24 network
4. D. configure a static route with 10.10.10.2 as the next hop to reach the 20.20.20.0/24 network

Correct Answer: D

- (Exam Topic 5)



IP connectivity and OSPF are preconfigured on all devices where necessary. Do not make any changes to the IP addressing or OSPF. The company policy uses connected interfaces and next hops when configuring static routes except for load balancing or redundancy without floating static. Connectivity must be established between subnet 172.20.20.128/25 on the Internet and the LAN at 192.168.0.0/24 connected to SW1:
* 1. Configure reachability to the switch SW1 LAN subnet in router R2.
* 2. Configure default reachability to the Internet subnet in router R1.
* 3. Configure a single static route in router R2 to reach to the Internet subnet considering both redundant links between routers R1 and R2. A default route is NOT allowed in router R2.
* 4. Configure a static route in router R1 toward the switch SW1 LAN subnet where the primary link must be through Ethernet0/1. and the backup link must be through Ethernet0/2 using a floating route. Use the minimal administrative distance value when required.
Solution:
Answer as below configuration:
On R2:
Enable Conf t
Ip route 192.168.1.0 255.255.255.0 10.10.31.1
On R1:
Enable Conf t
Ip route 0.0.0.0 0.0.0.0 10.10.13.3
On R2
Ip route 172.20.20.128 255.255.255.128 e0/2
Ip route 172.20.20.128 255.255.255.128 e0/1
On R1
Ip route 192.168.0.0 255.255.255.0 e0/1
Ip route 192.168.0.0 255.255.255.0 10.10.12.2 3
Save all configurations after every router from anyone of these command Do wr
Or
Copy run start

Does this meet the goal?

1. A. Yes
2. B. No

Correct Answer: A

- (Exam Topic 4)
What is the definition of backdoor malware?

1. A. malicious code that is installed onto a computer to allow access by an unauthorized user
2. B. malicious code with the main purpose of downloading other malicious code
3. C. malicious program that is used to launch other malicious programs
4. D. malicious code that infects a user machine and then uses that machine to send spam

Correct Answer: A
