- (Exam Topic 2)
Refer to the exhibit.

The default-information originate command is configured under the R1 OSPF configuration After testing workstations on VLAN 20 at Site B cannot reach a DNS server on the Internet Which action corrects the configuration issue?

1. A. Add the default-information originate command onR2
2. B. Configure the ip route 0.0.0.0 0.0.0.0 10.10.10.18 command on R1
3. C. Configure the ip route 0.0.0.0 0.0.0.0 10.10.10.2 command on R2
4. D. Add the always keyword to the default-information originate command on R1

Correct Answer: B

- (Exam Topic 1)
What is the difference in data transmission delivery and reliability between TCP and UDP?

1. A. TCP transmits data at a higher rate and ensures packet deliver
2. B. UDP retransmits lost data to ensure applications receive the data on the remote end.
3. C. UDP sets up a connection between both devices before transmitting dat
4. D. TCP uses the three-way handshake to transmit data with a reliable connection.
5. E. UDP is used for multicast and broadcast communicatio
6. F. TCP is used for unicast communication and transmits data at a higher rate with error checking.
7. G. TCP requires the connection to be established before transmitting dat
8. H. UDP transmits data at a higher rate without ensuring packet delivery.

Correct Answer: D

- (Exam Topic 1)
Which technology allows for multiple operating systems to be run on a single host computer?

1. A. virtual routing and forwarding
2. B. network port ID visualization
3. C. virtual device contexts
4. D. server visualization

Correct Answer: D

- (Exam Topic 3)
A network administrator is setting up a new IPv6 network using the 64-bit address 2001 0EB8 00C1 2200:0001 0000 0000 0331/64 To simplify the configuration the administrator has decided to compress the address Which IP address must the administrator configure?

1. A. ipv6 address 21:EB8:C1:2200:1::331/64
2. B. ipv6 address 2001:EB8:C1:22:1::331/64
3. C. ipv6 address 2001 :EB8:C 1:2200.1 ::331-64
4. D. ipv6 address 2001:EB8:C1:2200:1:0000:331/64

Correct Answer: C

- (Exam Topic 4)
Drag and drop the Rapid PVST+ forwarding state actions from the left to the right. Not all actions are used.

Solution:
* 1. BPDUs received are forwarded to the system module.
* 2. Frames received from the attached segment are processed.
* 3. Switched frames received from other ports are advanced.
* 4. The port in the forwarding state responds to network management messages. https://www.cisco.com/c/en/us/td/docs/switches/datacenter/nexus5000/sw/layer2/503_n1_1/Cisco_n5k_layer2_c

Does this meet the goal?

1. A. Yes
2. B. No

Correct Answer: A
