- (Exam Topic 4)
Which cable type must be used to interconnect one switch using 1000 BASE-SX GBiC modules and another switch using 1000 BASE-SX SFP modules?

1. A. LC to SC
2. B. SC t ST
3. C. SC to SC
4. D. LC to LC

Correct Answer: D

- (Exam Topic 2)
An administrator must secure the WLC from receiving spoofed association requests. Which steps must be taken to configure the WLC to restrict the requests and force the user to wait 10 ms to retry an association request?

1. A. Enable Security Association Teardown Protection and set the SA Query timeout to 10
2. B. Enable MAC filtering and set the SA Query timeout to 10
3. C. Enable 802.1x Layer 2 security and set me Comeback timer to 10
4. D. Enable the Protected Management Frame service and set the Comeback timer to 10

Correct Answer: C

- (Exam Topic 4)
What is a similarity OM3 and OM4 fiber optical cable?

1. A. Both have a 62.5 micron core diameter.
2. B. Both have a 50 micron core diameter.
3. C. Both have a 100 micron core diameter.
4. D. Both have a 9 micron core diameter.

Correct Answer: B

- (Exam Topic 2)
Refer to Exhibit.

An engineer is configuring the NEW York router to reach the Lo1 interface of the Atlanta router using interface Se0/0/0 as the primary path. Which two commands must be configured on the New York router so that it can reach the Lo1 interface of the Atlanta router via Washington when the link between New York and Atlanta goes down? (Choose two)

1. A. ipv6 router 2000::1/128 2012::1
2. B. ipv6 router 2000::1/128 2012::1 5
3. C. ipv6 router 2000::1/128 2012::2
4. D. ipv6 router 2000::1/128 2023::2 5
5. E. ipv6 router 2000::1/128 2023::3 5

Correct Answer: AE
Floating static routes are static routes that have an administrative distance greater than the administrative
distance (AD) of another static route or dynamic routes. By default a static route has an AD of 1 then floating static route must have the AD greater than 1. Floating static route has a manually configured administrative distance greater than that of the primary route and therefore would not be in the routing table until the primary route fails.

- (Exam Topic 4)
Refer to the exhibit.

What is the next hop for traffic entering R1 with a destination of 10.1.2 126?

1. A. 10.165 20.126
2. B. 10.165.20.146
3. C. 10.165.20.166
4. D. 10.165 20.226

Correct Answer: D
